77-20SR45I00020

Z

HD-1

HD RadioTM Receiver

OWNER’S MANUAL

HD Radio Receiver HD-1

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

IMPORTANT SAFETY INSTRUCTIONS

1)Read these instructions.

2)Keep these instructions.

3)Heed all warnings.

4)Follow all instructions.

5)Do not use this apparatus near water.

6)Clean only with dry cloth.

7)Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8)Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9)Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10)Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11)Only use attachments/accessories specified by the manufacturer.

12)Use only with the cart, stand, tripod,

b r a c k e t , o r t a b l e s p e c i f i e d b y t h e manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13)Unplug this apparatus during lightning storms or when unused for long periods of time.

14)Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

<Do not expose this apparatus to drips or splashes.

<Do not place any objects filled with liquids, such as vases, on the apparatus.

<Do not install this apparatus in a confined space such as a book case or similar unit.

<The apparatus draws nominal non-operating power from the AC outlet with its POWER switch in the off position.

<The apparatus should be located close enough to the AC outlet so that you can easily grasp the power cord plug at any time.

<An apparatus with Class ! construction shall be connected to an AC outlet with a protective grounding connection.

<Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.

<Excessive sound pressure from earphones and headphones can cause hearing loss.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

<DO NOT REMOVE THE EXTERNAL CASES OR CABINETS TO EXPOSE THE ELECTRONICS. NO USER SERVICEABLE PARTS ARE WITHIN!

<IF YOU ARE EXPERIENCING PROBLEMS WITH THIS PRODUCT, CONTACT TEAC FOR A SERVICE REFERRAL. DO NOT USE THE PRODUCT UNTIL IT HAS BEEN REPAIRED.

<USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

For U.S.A.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the equipment and/or the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV

technician for help.

CAUTION

Changes or modifications to this equipments not expressly approved by TEAC CORPORATION for compliance will void the user’s warranty.

Contents

Thank you for choosing TEAC. Read this manual carefully to get the best performance from this unit.

Important Safety Instructions . . . . . . . . . . . . . 2 Before Using the Unit. . . . . . . . . . . . . . . . 4

Connection . . . . . . . . . . . . . . . . . . . . 5 Unit Functions . . . . . . . . . . . . . . . . . . . 7 Display. . . . . . . . . . . . . . . . . . . . . . 9 Remote Control Unit. . . . . . . . . . . . . . . . . 9

Read this before operation

<As the unit may become warm during operation, always leave sufficient space around the unit for ventilation.

<The voltage supplied to the unit should match the voltage as printed on the rear panel. If you are in any doubt regarding this matter, consult an electrician.

<Choose the installation location of your unit carefully. Avoid placing it in direct sunlight or close to a source of heat. Avoid locations subject to vibrations and excessive dust, heat, cold or moisture.

<Do not place the unit on any other electronic components.

Teac Hdr9650ts Manual

<Do not open the cabinet as this might result in damage to the circuitry or electrical shock. If a foreign object should fall into the unit, contact your dealer or service company as soon as possible.

<When removing the power plug from a wall outlet, always pull directly on the plug. Do not pull on the line cord.

<Do not attempt to clean the unit with chemical solvents as this might damage the finish. Use a clean, dry, lint-free cloth.

<Keep this manual in a safe place for future reference.

Maintenance

•Place the unit on a level surface away from sources of direct sunlight or excessive heat.

•Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should be placed between it and the furniture.

•Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzine, thinner or similar materials can damage the surface of the unit.

Beware of condensation

When the unit is moved from a cold to a warm place, or used after a sudden temperature change, there is a danger of condensation; vapor in the air could condense on the internal mechanism, making correct operation impossible. To prevent this, or if this occurs, leave the unit for one or two hours with the power turned on. The unit will stabilize at the temperature of its surroundings.

Connection

CAUTION

<Switch off (standby) the power before making connections.

<Read the instructions of each component you intend to use with this unit.

<Be sure to insert each plug securely. To prevent hum and noise, do not bundle the connection cords .

A AC power cord

BPhones jack

CLine out jack D AUX IN jack

EVideo out jack

F AM loop antenna connector G FM antenna jack

HBattery compartment

A AC Power Cord

Be sure to connect the power cord to an AC outlet which supplies the correct voltage.

Hold the power plug when plugging or unplugging the power cord. Never pull or yank on the power cord.

B Phones jack

For private listening, first reduce the volume level to minimum. Then insert the plug from your headphones into the PHONES jack, and adjust the volume using the VOLUME knob. The sound from the speakers is cut off while the headphone jack is inserted.

CAUTION

Always lower the volume level prior to plugging in your headphones. TO AVOID DAMAGING YOUR HEARING - Do not place your headphones on your head until after you have plugged them in.

C Line out jack

You can connect this unit to an external amplifier, Connect the pin cords. Make sure to connect to MINI PLUG JACK.

NOTE :

<This output jack is a “line level” output. Do NOT connect to the “PHONO” jack on your amplifier or distortion may occur.

<The volume level of line output cannot be adjusted by the VOLUME control knob of this unit. Use the volume control of your amplifier to adjust the volume.

D AUX IN jack

You can connect a portable audio player to this jack. Connect the LINE OUT or PHONES jack (audio output jack) of the player using the supplied stereo mini plug cable.

When using the PHONES jack of your mini player, you must adjust the volume of the mini-player or you may hear no sound from your HD-1.

E VIDEO OUT jack

This terminal outputs video signal from iPod.

Use an RCA (pin) video cable to connect the Dock to the composite video connector of a television or monitor.

F AM loop antenna connector

Connect the supplied AM loop antenna to the AM ANTENNA connector.

Place the antenna in the direction which gives the best reception.

G FM antenna jack

While in FM mode, tune in an FM station and extend the lead to find the best position for the reception. This antenna may need to be repositioned if you move your unit to a new location.

H Battery compartment

The battery supplies a backup power to the builtin clock and preset, when the unit is momentarily disconnected from the AC outlet.

1. Remove the lid.

2.Insert two AAA batteries. 3. Replace the lid.

Battery replacement

If the clock comes to indicate the wrong time, replace the battery with a new one.

Precautions concerning AAA/UM-3 battery

<Be sure to insert the battery with correct positive “+” and negative “_” polarities. >

<Do not heat or disassemble battery and never dispose of old battery by throwing them in a fire. >

NOTE :

<The battery should be removed when not using it in a long term.

<The battery must use an alkaline battery on the market.
